Online DDL is a new feature in MariaDB 10.0. Online DDL is processed through below 4 tasks in sequence.

  1. InnoDB::ha_prepare_inplace_alter_table(..)
  2. InnoDB::ha_inplace_alter_table(..)
  3. InnoDB::ha_commit_inplace_alter_table(..)
  4. mysql_rename_table(..)

InnoDB storage engine allocates temporal memory buffer for transaction logging in phase 1 where row changes during this phase are logged. Size of this buffer is at start sort_buffer_size and it can be grown up to innodb_online_alter_log_max size. During phase 2 thread processing the ALTER statement will copy old table’s rows to a new altered table. After this MariaDB will take exclusive lock for target table and applies row log buffer to the new altered table.

This introduces a new unpredictable failure case row log buffer overflow. MariaDB server will rollback ALTER statement if row log buffer overflows. Thus, there is following problems:

  • If row log buffer size is too small the ALTER statement is rolled back and you have wasted precious time and resources.
  • If row log buffer is too big, you have wasted precious main-memory that could be used e.g. for buffer pool.
  • Currently, there is no way to see how much row log buffer is used and how much there is free space.
  • Currently, there is not even estimate how much work has been done and how much there is till to be done.
  • Currently, merge sort phase could also take a long time and there is no progress information.


There is two improvements in MariaDB 10.1: new status variables and progress information for online DDL.

New status variables and progress info

MariaDB Corporation would like to thank Matt, Seong Uck Lee from Kakao for contributing a patch that has now merged to MariaDB 10.1.

First of all there is three new global status variables.

  • Innodb_onlineddl_rowlog_rows: Shows how many rows is stored in the row log buffer.
  • Innodb_onlineddl_rowlog_pct_used: Shows row log buffer usage in 5-digit integer  (10000 means 100.00% ).
  • Innodb_onlineddl_pct_progress: Shows the progress of in-place alter table. It might be not so accurate because in-place alter is highly dependent on disk and buffer pool status.

Lets consider as an example where we have InnoDB table containing 150000 rows and we try to add a new column.

Concurrently, if we add new row, update some rows and delete few rows

This means that at the time of status statement there were 2003 rows on row log, 23\% of memory allocated for row log is used, and online alter table has completed 56.77\% of it’s work.

There is also additional output at error log, as example:

Merge sort progress

Additionally, show processlist statement will output estimate of index merge sort progress, e.g.


One of the most popular plugin types both in MariaDB and MySQL is INFORMATION_SCHEMA plugin type. INFORMATION_SCHEMA plugins add new tables to the INFORMATION_SCHEMA. There are lots of INFORMATION_SCHEMA plugins, because they can be used to show just anything to the user and are very easy to write.

MariaDB 10.1.1 comes with nine INFORMATION_SCHEMA plugin:

  • Feedback — shows the anonymised server usage information and can optionally send it to the configured url.
  • Locales — lists compiled-in server locales, implemented by Roberto Spadim
  • METADATA_LOCK_INFO — Lists metadata locks in the server. Implemented by Kentoku Shiba
  • QUERY_CACHE_INFO — Lists queries in the query cache. Originally by Roland Bouman
  • QUERY_RESPONSE_TIME — Shows distribution of query response times. Originally implemented in Percona
  • CLIENT_STATISTICS — part of Percona “userstat” patch
  • USER_STATISTICS — part of Percona “userstat” patch
  • INDEX_STATISTICS — part of Percona “userstat” patch
  • TABLE_STATISTICS — part of Percona “userstat” patch

Also there are many INFORMATION_SCHEMA plugins that come together with storage engines and show various information about them. InnoDB comes with 28 of such plugins. XtraDB — with 32, TokuDB — with 12. And if you google you can find many more INFORMATION_SCHEMA plugins — for example, a plugin that shows various system information or a plugin that lists all created user variables. INFORMATION_SCHEMA plugins are indeed numerous and very popular.

If you look at the these plugins, you can see that there are plugins that display some kind of a current state of something, and there are plugins that accumulate and display some statistics. For this second group of plugins it is sometimes desirable to reset this statistics — but there was no natural way for a user to do that. For status variables (as in SHOW STATUS statement) one can use FLUSH STATUS, but for plugins there was nothing similar. But now MariaDB 10.1.1 extends INFORMATION_SCHEMA plugin API by introducing reset_table callback. For example, look at the QUERY_RESPONSE_TIME plugin initialization function:

See the highlighted line — it sets the reset_table callback to the query_response_time_flush function. When this plugin is loaded, MariaDB will automatically start supporting new statement

and it will invoke this callback that will, in turn, reset query response time statistics. Similarly “userstat” tables CLIENT_STATISTICS, USER_STATISTICS, INDEX_STATISTICS, and TABLE_STATISTICS support the FLUSH statement in a similar way.

MariaDB 10.1.1 also implements another enhancement for the INFORMATION_SCHEMA plugins — the SHOW statement. Indeed, until 10.1.1 only native server INFORMATION_SCHEMA tables could have a SHOW counterpart. To query a plugin INFORMATION_SCHEMA table one would need to type a lengthy SELECT and than see how long lines wrap around in the terminal window, making it impossible to see what column each value belongs to. You all know it very well:

So we’ve introduced a SHOW statement for INFORMATION_SCHEMA plugins that is quick to type and is supposed to provide just enough columns to fit nicely on the screen:

The API is very simple, a plugin does not need to implement anything special to support this. It only needs to decide what subset of columns will be visible in the SHOW statement and specify names for this columns when declaring INFORMATION_SCHEMA table fields. For example, in the LOCALES plugin:

See, the highlighted lines specify column names for the SHOW statement and only these columns are visible in SHOW. It is, of course, a sole responsibility of the plugin writer to pick up a reasonable subset of columns so that the resulting table is not too wide but still contains enough information to be useful. If a plugin does not specify any column names for SHOW, the SHOW statement will not work for this plugin.

An inquisitive reader may note that “userstat” tables CLIENT_STATISTICS, USER_STATISTICS, INDEX_STATISTICS, and TABLE_STATISTICS supported FLUSH and SHOW also in 10.0 and in earlier versions of MariaDB. That’s right, but before 10.1.1 these tables were not plugins, and the syntax support was hard-coded into the server. Now they are plugins which, indeed, required INFORMATION_SCHEMA plugins to support FLUSH and SHOW. That’s why these extensions were implemented.

Every now and then there is a need to execute certain SQL statements conditionally. Easy, if you do it from your PHP (or Java or whatever) application. But if all you have is pure SQL? There are two techniques that MariaDB and MySQL use in the mysql_fix_privilege_tables.sql script (applied by mysql_upgrade tool).

  1. Create a stored procedure with IF statements inside, call it once and drop it. This requires the user to have the CREATE ROUTINE privilege and mysql.proc table must exist and be usable (which is not necessarily true — we’re doing it from mysql_upgrade, right?).
  2. Use dynamic SQL, like

    which is not very readable and doesn’t work well if you need to execute many statements conditionally.

This may be standard, but I never understood why one cannot simply use SQL control statements (besides CALL that is) directly from the mysql command line tool prompt. Imagine a bash variant that only supports if and while in scripts, but not in the interactive mode from the command line — how would you like it?

May be Antony Curtis was asking himself similar questions when he contributed a patch for compound statements in MDEV-5317. Either way, we thought it’s a great idea and implemented this feature, based on the Antony’s contribution.

Now one can use BEGIN, IF, CASE, WHILE, LOOP, REPEAT statements directly in SQL scripts and from the mysql command line prompt — outside of stored programs. For example, one can rewrite the above as

One can use BEGIN ... END blocks and loops without having CREATE ROUTINE privilege or with corrupted (or missing mysql.proc table). This all works as you would expect it to, with no artificial “standard says so” limitations.

Still, there are some limitations to keep in mind:

  • You cannot use a simple BEGIN to start a block, this is historically used to start a transaction. Use the standard syntax BEGIN NOT ATOMIC.
  • Compound statements from the mysql command line prompt cannot start with a label.
  • Not all statements that can be used in the stored program are supported from the mysql command line prompt, only those listed above are.

These limitations, though, only apply to the top-level statement. For example, if you need a labeled loop or SIGNAL, you start a block and put your statement inside it:
